CELLAVISTA 4
Fastest imager in the market - up to 50MB/s image acquisition
The CELLAVISTA® 4 is an automated ultrahigh-throughput imaging system that non-invasively measures brightfield and fluorescence assays in multi-well plates, chamber slides or RoboFlasks for an extremely broad range of cellular applications in cell line development, cellular research and drug discovery.
Discover all the advantages
COMPARE TECHNICAL SPECIFICATIONS
|
CELLAVISTA® 4K HighEnd1 |
CELLAVISTA® 4 Scientific |
|
|---|---|---|
|
Throughput |
250² plates / day |
250² plates / day |
|
Objective capacity |
4 |
4 |
|
Selectable Resolutions1 |
3.3 µm @ 2x optional |
6.5 µm @ 2x optional |
|
Automated whole well/whole plate imaging |
✓ |
✓ |
|
Sample types |
SBS plate format (1536, 384, 96 wells and less), culture dishes and microscope slides |
SBS plate format (1536, 384, 96 wells and less), culture dishes and microscope slides |
|
Camera |
8 bit progressive scan |
16 bit sCMOS |
|
Pixel density |
5440x 5440 |
2048 x 2048 |
|
Quantum efficiency |
~57 % |
> 80 % |
|
Light source |
High performance long-life LED |
High performance long-life LED |
|
Illumination / Fluorescence1 |
Brightfield and 6 fluorescence excitation/emission channels |
Brightfield and 6 fluorescence excitation/emission channels |
|
Temp.-& CO2 control |
Possible3 |
Possible3 |
|
Image acquisition- & device controlling software4 |
YT-SOFTWARE®4 |
YT-SOFTWARE®4 |
|
Automation-ready set up |
✓ |
✓ |
|
Software-interface for automation |
✓ |
✓ |
|
Batch processing interface |
✓ |
✓ |
|
External barcode-reader |
Optional |
Optional |
1 Different system configurations like e.g. basic systems with brightfield only or customized filter and objective lenses set-ups are available.
2 Throughput per day depends on experiment configurations (e.g. exposure time, plate type, focus options, # of imaging channels…).
3 CELLAVISTA® can be combined with an external incubation and plate handling option (SYBOT X-1000 or other automation systems), whereby the plates are only outside the incubator during the measuring time.
4 YT-SOFTWARE® includes the same image analysis tools for both CELLAVISTA® and NYONE®. Differences in usable applications arise only due to different hardware configurations (e.g. different illuminations or camera chips).
5 Hardware automation-package available.
Advanced Technological Features
- Enhanced harmonic motion for imaging without agitation during plate scan
- Ultrafast multiplex imaging
- Highly sensitive optics for perfect resolution
- HCS-grade lenses
- 3 times more sensitive fluorescence module enabling shorter exposures
- Faster measurements and less photobleaching than ever before
- Autofocus performance is twice as fast as in previous models
To get an overview of our imager and their characteristics please see 'Compare Technical Specifications' on Product page.
Different Variants of CELLAVISTA® 4
SCIENTIFIC Line – More than high resolution
Featuring high-sensitivity 16-bit sCMOS cameras combined with high numerical aperture objectives, the SCIENTIFIC instrument series achieve better resolution in a higher dynamic range and employ a quantum efficiency of more than 80% (relevant to detect weak fluorescence). This enables the performance of higher dynamic range assays due to a better signal-to-noise (S/N or SNR) ratio.
CELLAVISTA® 4K - No artificial calculations, just pure resolution
The first automated 4K cell imager series with high throughput and configurable resolution settings (data compression) - because resolution can matter!
We have invested a lot of time and know-how to achieve this true 0.8 µm resolution at 10x. This gives you the possibility especially in brightfield area to check for monoclonality of your SCC applications and not miss a single cell fragment.
